GPSM-40G13-20LR

Overview

The GPSM-40G13-20LR QSFP+ Transceiver is a high-performance optical module designed for 40 Gigabit Ethernet applications over Single Mode Fiber (SMF). Compliant with the IEEE 802.3ba 40GBASE-LR4 standard, the module converts four independent 10Gbps electrical input channels into four CWDM optical signals and multiplexes them into a single optical link for 40Gbps transmission. Designed for long-range connectivity, it supports transmission distances of up to 20km, making it ideal for data centers, enterprise backbones, and telecom networks.

Key Features

• • Compliant with IEEE 802.3ba 40GBASE-LR4 and QSFP+ MSA standards
  • Utilizes 4 CWDM lanes with integrated MUX/DEMUX technology
  • Supports data rates of up to 11.2Gbps per channel
  • Delivers an aggregate bandwidth of over 40Gbps
  • Features a duplex LC optical connector interface
  • Enables transmission distances of up to 20km over Single Mode Fiber (SMF)
